OT - Any masons on here? Question about tuck pointing....

odie91odie91 Posts: 518
What's the best way to repair this?   It's like a front veneer of the bricks have come off.  The building was built around 1955.

  Should I:

- Take the bricks out, and replace them?   Some of the bricks are below the level of the pavement (not sure how that happened, maybe the pavement was built up later on) -- so it would  be hard to get to replace the lower bricks.

- Hollow the damaged areas out (taking out the brick and mortar) and replace it wholly with just mortar?   The cosmetics might look off, but I'm okay with that.    Type S or Type N for this job?

- Other

Thanks in advance


Comments

  • odie91odie91 Posts: 518

  • SGHSGH Posts: 25,991
    I am. Just not a brick mason.

    Location- Just "this side" of Biloxi, Ms.

    Status- Standing by.

    Arsenal-Just a small wore out and broken down Weber kettle. No other means to cook at all.

    Virtus Junxit Mors Non Separabit

    The greatest barrier against all wisdom, the stronghold against knowledge itself, is the single thought in ones mind, that they already have it all figured out.

    Just a man with a Muhle.

  • thetrimthetrim Posts: 8,015
    Thought you might want the secret handshake and the location of the Holy Grail.
    =======================================
    XL 6/06, Mini 6/12, L 10/12, Mini #2 12/14 MiniMax 3/16
    Tampa Bay, FL
    EIB 6 Oct 95
  • KomokaeggerKomokaegger Posts: 58
    It looks like someone has tried patching this before. There should have been some type of expansion joint material between the asphalt and the brick. Not sure where you’re located but it appears water has got into the brick and then frozen causing it to fracture. Also you could be having movement between the asphalt and brick due to heat. It doesn’t look like you would have much brick left to work with if you tried removing them.
    Ontario, Canada
    XL- BGE
    CGS- AR, spider, PS WOO,
    KAB
  • ewyllinsewyllins Posts: 426
    thought you were pointing to the east
    O-Town, FL

  • pgprescottpgprescott Posts: 11,706
    It is never advisable to lay brick below grade IMO. Particularly in areas of the country that experience freezing. That's toast. Removal required. I don't really think the flexible asphalt is a major factor, especially if the opposing side of the drive is bordered by soil.

    Masonry construction leaks and wicks water. It should be designed to allow the water to migrate to a VB and then downward to a flashing and weep hole system. It appears as though the water has no where to go and then froze and spalled the brick as mentioned above. You are going to need to seek on site advice I'm afraid. If this is against wood framing you may have rot issues on the back side. If it is veneered over concrete, you can repair it but it's a pain. Make sure there is flashing above grade and weep holes for the moisture?water to escape the wall cavity.

    Good Luck!
  • northGAcocknorthGAcock Posts: 12,252
    edited March 12
    This is where my mind went from the Post heading. Sorry no help on the brick side.


    Columbia, South Carolina with a Medium, MiniMax & a 17" Blackstone

    “Constantly choosing the lesser of two evils is still choosing evil.”
  • lkapigianlkapigian Posts: 4,585
    My first thought----My apologies, no help on the bricks either


    Visalia, Ca
  • MaskedMarvelMaskedMarvel Posts: 2,405
    Salting the asphalt in icy conditions can cause that damage as well.
    Large BGE and Medium BGE
    36" Blackstone - Greensboro!


  • ThatgrimguyThatgrimguy Posts: 3,994
    Definitely thought this was going to be a Freemason thread.
    XL & Small Green Egg, Shirley Fab Trailer, Pitmaker Vault, Blackstone Griddle, 6 gal Cajun Fryer, BlueStar 60" Range
  • pgprescottpgprescott Posts: 11,706
    Salting the asphalt in icy conditions can cause that damage as well.
     Agreed.

    The salt is just a symptom though. It simply aides in creating the freeze thaw issue within the face brick.
  • SGHSGH Posts: 25,991
    This is where my mind went from the Post heading. Sorry no help on the brick side.


    Did any of y’all notice what the lady in the crowd was wearing? Overall shorts. You can see her at about 12 seconds in. I have a keen eye for such.

    Location- Just "this side" of Biloxi, Ms.

    Status- Standing by.

    Arsenal-Just a small wore out and broken down Weber kettle. No other means to cook at all.

    Virtus Junxit Mors Non Separabit

    The greatest barrier against all wisdom, the stronghold against knowledge itself, is the single thought in ones mind, that they already have it all figured out.

    Just a man with a Muhle.

  • nolaeggheadnolaegghead Posts: 29,860
    Image result for brick below grade

    ______________________________________________
    This is my signature line just so you're not confused.  Love me or hate me, I am forum Marmite.
    Large and Medium BGE, Kamado Joe Jr, Akorn Jr, smoker with a 5k btu AC, gas grill, fire pit, pack of angry cats, two turntables and a microphone, my friend.  Registered republican.
    New Orleans, LA - we know how to eat

  • nolaeggheadnolaegghead Posts: 29,860
    Image result for brick below grade
    ______________________________________________
    This is my signature line just so you're not confused.  Love me or hate me, I am forum Marmite.
    Large and Medium BGE, Kamado Joe Jr, Akorn Jr, smoker with a 5k btu AC, gas grill, fire pit, pack of angry cats, two turntables and a microphone, my friend.  Registered republican.
    New Orleans, LA - we know how to eat

  • alaskanassasinalaskanassasin Posts: 1,450
    Could have been caused by a sloppy weed whacker operator as well....
    South of Columbus, Ohio.
  • ckali7ckali7 Posts: 114
    SGH said:
    I am. Just not a brick mason.
    . . .
  • MaskedMarvelMaskedMarvel Posts: 2,405
    Image result for brick below grade

    My house circa 1930 has: Brick veneer
    Large BGE and Medium BGE
    36" Blackstone - Greensboro!


  • EoinEoin Posts: 2,335
    The brick courses at / below ground level would be engineering brick in this country. There is no point trying to save those bricks, except as a very temporary measure. Nola's schematic is good. To do the job properly, you need to cut back the asphalt and replace the damaged bricks, then reinstate the path properly.
